Tianjin Tanggu TWT Valve Co., Ltd was founded in 1956, main in producing and supplying products like Butterfly Valve, Gate Valve, Globe Valve and so on, our products are selled to South East Asia, South America, Middle-East and other markets.

Needle Valve

Needle Valve
  • Model Number: NRV
  • Brand Name: TWT
  • Place of Origin: Shanghai, China
  • Minimum Order Quantity: 100
  • Supply Capacity: 10000/month
  • Payment: T/T, D/P, L/C, Western Union
  • MemberShip: Free Member
  • Inquiry Now
  • Bookmark & Share:

NRV Needle Valve Description

The Need Valve offers an axisymmetric shape and design of double seal of metal and elastic material which gives the water flow the space to always annular in the valve cavity. It shrinks to the axis at the outlet to avoid throttling to eliminate damage to the pipe network and piping caused by cavitation and vibration. The Needle Valve has an ideal geometric design, the fluid is well guided inside the streamlined valve body. Even in the case of high pressure difference. The valve can also effectively eliminate the high pressure difference, the high pressure reduced to low pressure, and will not produce vibration and cavitation occurrence. The continuous decreasing area of the annular runner from the inlet to the shrinkage section leads to the gradual increase of the flow rate without cavitation, and does not produce the energy conversion of cavitation damage. Whether the piston is in any position, the shrinkage section is annular, ensuring perfect linear adjustment characteristics.

Application Water Industrial Usage, Industrial Usage
Pressure Pn0.6 ~ 6.4MP
Temperature of Media -10~120℃
Structure Needle Valve
Operation Gear, Pneumatic, Electric, Hydraulic
Material Ductile Iron, Carbon Steel, Stainless Steel
Media Water Oil Gas etc.
Connection Mode Flange
