JYWQ automatic stir sewage submersible pump

JYWQ automatic stir sewage submersible pump
  • Model Number: 80JYWQ50-10-1600-3
  • Brand Name: kenshine-pump.com
  • Place of Origin: Shanghai, China
  • Minimum Order Quantity: 1Set
  • Supply Capacity: 1000sets per month/month
  • Payment: T/T in advance
  • MemberShip: Gold Member
  • Inquiry Now
  • Bookmark & Share:

80JYWQ50-10-1600-3 JYWQ automatic stir sewage submersible pump Description

JYWQ series automatic stir sewage pump is on the basis of the general sewage pump  and adopts automatic mixing device. The mixing device rotates with the motor shaft and has extremely strong stirring power. Sediment into sewage is mixed into suspension and sucked by the pump and finally discharged. It improves the pump to collect, drainage capacity so as to complete a one-time drainage, sewage disposal, in addition to the deposition and save operating costs. The pump has the obvious advancement and use as environmental protection pump.

Features

1.When the automatic mixing sewage pump is running, the sediment into the bottom of tank is automatically mixed, thoroughly prevent dirt deposition, without manual cleaning;

2.Unique impeller design, with fiber, debris shredding and tearing function;

3.External circulation cooling system is adopted to make sewage pump run at low water level, reduce motor starting frequency and extend motor life.

Model meaning of JYWQ automatic mixing sewage pump

Example: 80JYWQ50-10-1600-3

80-discharge diameter (mm)

JYWQ-automatic mixing sewage pump

50-flow (m3/h)

10-head (m)

1600-mixing range (mm)

3-motor power (KW)

Application:

1.The discharge of waste water seriously polluted by factories and businesses.

2.Sewage treatment plants, hospitals, hotels drainage system.

3.A sewerage station for residential areas.

4.The water supply equipment of air defense drainage station and water works.

5.Municipal engineering, construction site.

6.Auxiliary machinery for exploration, mining and power plants.

7.Rural biogas pool, farmland irrigation, river pond dredging.


flow rate 2-600m3/h
head 3-60m
pump material cast iron or stainless steel
