Ningbo Fenghua Gogo Automatic Trading Company Limited was founded in 2014, main in producing and supplying products like Solenoid valve, Air Control Valve, ball valve and so on, our products are selled to Eastern Europe, South America, North America and other markets.

Industrial 3 Way Air Compressor High Pressure Solenoid Air Valve

Industrial 3 Way Air Compressor High Pressure Solenoid Air Valve
  • Model Number: GG-004
  • Brand Name: GOGO ATC
  • Place of Origin: Zhejiang, China
  • Minimum Order Quantity: 50 Pieces
  • Supply Capacity: 40000 Pieces/month
  • Payment: L/C,D/A,D/P,T/T,Western Union,MoneyGram
  • MemberShip: Free Member
  • Inquiry Now
  • Bookmark & Share:

GG-004 Industrial 3 Way Air Compressor High Pressure Solenoid Air Valve Description

GG23JD-15 2.4Mpa or 3.5 Mpa three-way air compressor high pressure safety solenoid air valve

1. Classical design,durable ai control design
2. Engery saving and environmental protection with big low rate,safety and precision
3. Can work at the low pressure,smartness for on and off,good seal performance
4. Single action and double action types for your selection
5. Widely used in the food,machin,industry,abstersion,lanification,printing and other area

Model:                           GG23JD-8 GG23JD-8P2         GG23JD-15 GG23JD-15P2

Applicable medium:              air

Nomial diameter:                   8mm                                        15mm

Lubrication: no oil

Pipe size:                                G1/4                                   G1/2

Pressure range: 0.15 ~ 2.4MPa

Applicable temperature:  -5 ~ 50°C

1 years warranty

Maintenance instructions:
1. attention to check the use of components, in the transport process is damaged, and then install the use of.
2. When installing, please note that the gas flow direction and the takeover are correct.
3. when using, please strictly comply with the technical requirements, such as the operating voltage, operating frequency, working pressure, the use of temperature, the whole machine debugging, it is recommended to use a manual device debugging, and then through power debugging.
4. Please pay attention to dust, it is recommended to install the exhaust port or muffler muffler throttle.
5. When connecting pipe, pay attention to only release the strap around the joint may not exceed the end face of the tooth, and pay attention to the elimination of pipe fittings, metal particles inside the pipe, dust and oil, etc


Packaging & Shipping
1:Inner packing: opp bag, then carton box for each product.
2:Outer packing: export standard carton, Foam outside protecting the goods against damage


1: Various style for each products and completely series pneumatic products for you to choose from.
2: Large stock for fast shipping.
3: High quality with competitive price
4: Sample order & small quantity order is ok

5:Customize according to your special demand.
6: Provide free products information.
7. Reliable quality assured and active after-sell service

Nomial Diameter 8MM / 15MM
Applicable Medium AIR
Pipe Size 1/4 1/2
Applicable Temperature -5~50℃
